ABS-certified ACCU compliance
Designed for unattended machinery-space operation in accordance with ABS requirements.
Projects / Integrated Automation
← All ProjectsIntegrated Automation for a 25,900 DWT Chemical Tanker
An ABS-certified platform unifying machinery monitoring, alarms and remote valve control.
- Vessel Type
- Stainless steel chemical tanker
- Capacity
- 25,900 DWT
- Classification
- ABS · ACCU notation
- Client
- MAC SHIPPING
Project Overview
MAC SHIPPING required an integrated automation system for a 25,900 DWT stainless steel chemical tanker. ASI delivered a Siemens PLC-based architecture combining the Engine Room Monitoring and Alarm System (AMS) with Valve Remote Control (VRC), supported by configuration, installation guidance, commissioning and handover services.
Key Highlights
Integrated AMS and VRC
Machinery monitoring, alarms and remote valve control operate on one unified ASI platform.
Dual-redundant architecture
Independent control and operation domains use ring and dual A/B network redundancy.
Multi-tier alarm response
Critical alarms extend to the bridge and crew accommodation, with fail-safe escalation if unanswered.
Project Gallery
